High Precision Wafer Heater Customized Wafer Hot Plate

Product Details:
Place of Origin: Suzhou, China
Brand Name: GoGo
Certification: ISO 9001:2015 / ISO 14001:2015 / ISO 45001:2018
Model Number: /
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: CNY 30000~600000/set
Packaging Details: Cardboard box + wooden box
Delivery Time: 30~60 work days
Payment Terms: T/T
Supply Ability: 1set/day
Contact Now Chat Now

Detail Information

Name: Wafer Heater Product Features Detailed Product Specifications Download TYPE Wafer Heating Device Size: 2/4/6/8/10/12 Inch
Temperature Range: RT~600℃ Temperature Stability: ±0.1℃
Material: Aluminum Alloy, Stainless Steel, Invar®, Etc. Flatness: ≤10μm,Can Achieve 3μm, Depending On The Material
Suitable Environment: Vacuum/Atmosphere Cooling System: Options: Water Cooling, Air Cooling, Etc.
Bonding Pressure: Options:0~100kN
Highlight:

High Precision Wafer Heater

,

Wafer Heater Customized

,

Customized Wafer Hot Plate

Product Description

High-Precision Wafer Heater with ±0.1°C Temperature Stability, ≤10µm Flatness at High Temp, and RT~600°C Range for Semiconductor Processes

Product Title: GoGo High-Precision Wafer Heater for Advanced Semiconductor Processes
Product Introduction

The GoGo High-Precision Wafer Heater is a core thermal processing solution engineered for the demanding requirements of modern semiconductor fabrication and research. It plays a critical role in key wafer-level processes such as high-temperature bonding, annealing, thin-film deposition, and lithography. This advanced Wafer Heater delivers exceptional temperature control accuracy (±0.1°C) and superior temperature uniformity across the entire platen, ensuring a stable and repeatable thermal environment. Engineered to maintain exceptional flatness at high temperatures (≤10µm, down to 3µm optionally), it provides the reliable, uniform heating foundation essential for next-generation device manufacturing and R&D.

Key Advantages & Why Choose Our Wafer Heater
  • Unmatched Thermal Precision & Uniformity: Achieves laboratory-grade temperature stability of ±0.1°C with outstanding cross-wafer uniformity. This precision is critical for consistent process results, high yield, and reproducible research in sensitive semiconductor applications.
  • Engineered for High-Temperature Flatness: The platen is meticulously designed and manufactured from low-thermal-expansion materials (e.g., Invar®) to maintain exceptional flatness (as low as 3µm) even at maximum operating temperatures up to 600°C, preventing wafer warpage and ensuring perfect contact.
  • Full Customization for Your Process: Our Wafer Heater is fully configurable. Choose from standard wafer sizes (2" to 12"), various platen materials (Al alloy, stainless steel, Invar®), bonding pressure options (0-100kN), and cooling systems (water/air) to perfectly match your specific process needs.
  • Versatile for R&D and Pilot Production: Suitable for both controlled atmosphere and vacuum environments, this system supports a wide range of applications from fundamental academic research on novel materials to process development and small-batch pilot production in industrial settings.
  • Certified Quality for Critical Operations: Manufactured under ISO 9001:2015, 14001:2015, and 45001:2018 certified management systems, ensuring every Wafer Heater meets the highest standards of reliability, safety, and performance required in semiconductor environments.
Technical Specifications
Parameter Specification / Options
Product Type Wafer Heater / Heating Chuck
Wafer Size Compatibility 2", 4", 6", 8", 10", 12" (Customizable)
Temperature Range RT ~ 600°C
Temperature Stability ±0.1°C
Platen Flatness at High Temp ≤10µm (Standard), down to 3µm (Optional)
Platen Material Aluminum Alloy, Stainless Steel, Invar®, etc.
Process Environment Vacuum or Atmospheric
Optional Features Integrated Bonding Pressure (0-100kN), Water/Air Cooling
Target Markets & Clients

This professional-grade Wafer Heater is designed to support the growing semiconductor sector in key international markets including Southeast Asia, the Middle East, Russia, and Africa. It is an essential tool for university microelectronics research labs, semiconductor research institutes, and high-tech companies engaged in MEMS, advanced packaging, compound semiconductor, and integrated circuit development.

Frequently Asked Questions (FAQ)
  1. What is the primary application of this Wafer Heater?
    It is used for precise thermal processing in semiconductor and microsystem fabrication, including wafer bonding, annealing, curing, and as a stable hot chuck for processes like spin-coating or inspection that require controlled heating.
  2. Why is platen flatness so important at high temperatures?
    Maintaining flatness prevents wafer bending or poor interfacial contact during bonding or deposition, which can lead to defects, voids, and device failures. Our heater is specifically engineered to minimize thermal deformation.
  3. Can the system be integrated into our existing vacuum chamber or tool?
    Yes. The Wafer Heater is designed as a modular subsystem. We provide detailed mechanical and electrical interfaces and can work with you to ensure seamless integration into your custom or OEM process chamber.
  4. How do I choose the right platen material?
    The choice depends on your process temperature, required flatness, and compatibility. For example, Invar® offers the lowest thermal expansion for ultra-high flatness, while aluminum provides excellent thermal conductivity for rapid heating.
  5. What control system is used?
    The system is typically integrated with our high-precision TNEX temperature control platform, offering programmable multi-segment recipes, real-time monitoring, and data logging for full process traceability.
